Despite major developments in this field, faults still occur frequently in cable systems for various reasons. In addition to trained personnel, you also need very efficient equipment to rectify faults.
Cable fault location devices and systems from BAUR cover the entire cable fault location process:
The initial fault analysis provides the basis for determining the subsequent procedure in the fault location process. During pre-location, the position of the fault is roughly located. The subsequent pin-pointing enables precise determination of the cable fault. Cable identification is used to identify the defective cable in a route. You can use various measurement methods depending on the type of fault and cable type.
All products: Cable fault location
ATG 2
Burn down transformer
with max. voltage of 10 kV
ATG 6000
Burn down transformer
with max. voltage of 15 kV
BAUR Software 4
Software package
for cable fault location, cable testing and cable diagnostics
CL 20
Handy device
for locating cable routes
and metal pipes
frida
VLF tester
for medium-voltage cables
up to 36 kVpeak
IRG 400 / IRG 400 portable
Time domain reflectometer / echometer
IRG 4000
Time domain reflectometer (TDR)
for cable lengths up to 1000 km
IRG 4000 portable
Portable time domain
reflectometer (TDR)
for cable lengths up to 1000 km
KSG 200
Cable identification system
for use on de-energised and
live low-voltage cables
PGK 110 HB
Voltage test
with DC or AC 50 Hz
110 kV, 14 mA
PGK 110/5 HB
Voltage test
with DC or AC 50 Hz
110 kV, 66 mA
PGK 150 HB
Voltage test
with DC or AC 50 Hz.
150 kV, 9 mA
PGK 150/5 HB
Voltage test
with DC or AC 50 Hz
150 kV, 50 mA
PGK 25
DC HV tester
for use on low- and
medium-voltage cables up to 25 kV
PGK 70/2.5 HB
Voltage test
with DC or AC 50 Hz.
70 kV, 50 mA
PHG 80 portable
VLF tester
for medium-voltage cables
up to 80 kVpeak
PHG 80 TD
VLF tester and diagnostics device (TD)
for medium-voltage cables
up to 80 kVpeak
PHG 80 TD PD
VLF tester and
diagnostics device (TD and PD)
for medium-voltage cables
up to 80 kVpeak
protrac®
ALL-IN-ONE
cable fault location and
tracing system
shirla
Portable device
for cable sheath testing
and fault location
SSG 1100
Surge voltage generators,
max. surge energy: 1100 J
Voltage: 0 – 8, 16, 32 kV
SSG 1500
Surge voltage generators,
max. surge energy: 1536 J
Voltage: 0 – 8, 16, 32 kV
SSG 2100
Surge voltage generators,
max. surge energy: 2048 J
Voltage: 0 – 8, 16, 32 kV
SSG 3000
Surge voltage generators,
max. surge energy: 3000 J
Voltage: 0 – 8, 16, 32 kV
